Sensor Information for UMOOS Mooring: E0143
Mooring History:
| Date | Buffer Name | Data Type | Depth | Comments |
|---|
| 2024-05-04 14:55 | ALL | ALL | | Deployed by R/V Connecticut |
Notes: Sensors highlighted in red indicate problems with
this sensor during deployment. Depth is measured relative to the ocean surface with positive depths
indicating depths below the ocean surface. Negative depths are heights above
the surface. In the case of doppler current measurements, the depth indicates
depth of first measurement:delta-depth:depth of last measurement. For instance,
10:4:106 represents currents measured every 4 meters from 10 meters down to 106
meters (28 depths in all).
| Data Type | Depth (m) | Real Time | Sensor S/N | Manufacturer | Model | Sample Interval | Averaging Period (min) | Update Interval (min) | Units | Accuracy |
|---|
| visibility | -3 | Y | AANVS874 | Aanderaa_Instruments | 3544 | 1 hz | 8 | 10.0 | m | 10.0000 |
| air_temperature | -3 | Y | CAMAT002 | Campbell | 107 | 1 sample/8 seconds | 8 | 10.0 | deg C | 0.9000 |
| barometric_pressure | -3 | Y | SETPR2299993 | Setra | 270 | 1 hz | 8 | 10.0 | millibars | 1.0000 |
| gps_lat | -4 | Y | BAEGP010709 | BAE/NavTech/Canadian_Marconi | 100-601903-002 | 1 sample/hour | 0.0 | 60.0 | degrees | 0.0002 |
| wind_2_gust | -4 | Y | GILMX23460006 | | | 5 sec | 8 | 10.0 | | |
| wind_2_direction | -4 | Y | GILMX23460006 | | | 1 hz | 8 | 10.0 | | |
| wind_2_speed | -4 | Y | GILMX23460006 | | | 1 hz | 8 | 10.0 | | |
| wind_gust | -4 | Y | RMYWM168666 | RM_Young | 05106-5 | 5 sec | 8 | 10.0 | m/s | 0.3000 |
| wind_direction | -4 | Y | RMYWM168666 | RM_Young | 05106-5 | 1 hz | 8 | 10.0 | degrees | 10.0000 |
| wind_speed | -4 | Y | RMYWM168666 | RM_Young | 05106-5 | 1 hz | 8 | 10.0 | m/s | 0.3000 |
| gps_lon | -4 | Y | BAEGP010709 | BAE/NavTech/Canadian_Marconi | 100-601903-002 | 1 sample/hour | 0.0 | 60.0 | degrees | 0.0002 |
| dominant_wave_period | 0 | Y | SUMAC0902A01078 | Summit | 34203A | 2 hz | 17 | 30.0 | seconds | 1.0000 |
| significant_wave_height | 0 | Y | SUMAC0902A01078 | Summit | 34203A | 2 hz | 17 | 30.0 | meters | 0.3000 |
| int_temp | 0 | Y | UMECB119 | University_of_Maine | GOM01 | 1 sample/hour | 0.0 | 60.0 | deg C | 0.9000 |
| temperature | 1 | Y | SBESM26672 | Sea-Bird_Electronics_Inc | 37SM.10200 | 1 sample | 0 | 30.0 | | |
| conductivity | 1 | Y | SBESM26672 | Sea-Bird_Electronics_Inc | 37SM.10200 | 1 sample | 0 | 30.0 | | |
| conductivity | 10 | Y | SBEIM22644 | Sea-Bird_Electronics_Inc | SBE37IM | 1 sample | 0 | 60.0 | mS/cm | 0.0100 |
| temperature | 10 | Y | SBEIM22644 | Sea-Bird_Electronics_Inc | SBE37IM | 1 sample | 0 | 60.0 | deg C | 0.0050 |
| current_v | 2 | Y | AANSG1025 | Aanderaa_Instruments | SeaGuard | 10 hz | 1 | 60.0 | | |
| current_u | 2 | Y | AANSG1025 | Aanderaa_Instruments | SeaGuard | 10 hz | 1 | 60.0 | | |
| temperature | 2 | Y | AANSG1025 | Aanderaa_Instruments | SeaGuard | 1 sample | 0 | 60.0 | | |
| conductivity | 20 | Y | SBEIM2562 | Sea-Bird_Electronics_Inc | SBE37IM | 1 sample | 0 | 60.0 | mS/cm | 0.0100 |
| temperature | 20 | Y | SBEIM2562 | Sea-Bird_Electronics_Inc | SBE37IM | 1 sample | 0 | 60.0 | deg C | 0.0050 |
| conductivity | 50 | Y | SBEIM26740 | Sea-Bird_Electronics_Inc | 37IMP.13002 | 1 sample | 0 | 60.0 | | |
| temperature | 50 | Y | SBEIM26740 | Sea-Bird_Electronics_Inc | 37IMP.13002 | 1 sample | 0 | 60.0 | | |
| current_u | ::0 | Y | RDIWK1848 | RD_Instruments | WHS-300 | 1 sample/6 sec | 8 | 60.0 | cm/sec | 0.5000 |
| current_v | ::0 | Y | RDIWK1848 | RD_Instruments | WHS-300 | 1 sample/6 second | 8 | 60.0 | cm/sec | 0.5000 |
